Feature
A series regulator is equivalent SMC series FRL.
Filter out the water molecule and dust, lubricate the oil and regulate the compressed air.
Specification
Model | AF1500 | AF2000 | BF2000 | BF3000 | BF4000 |
Medium | Air | ||||
Port size(G) | 1/8 | 1/4 | 1/4 | 3/8 | 1/2 |
Drain capacity | 15cm3 | 60cm3 | |||
Max.burst pressure | 15kgf/cm2 | ||||
Max.operating pressure | 9.9kgf/cm2 | ||||
Regulating range | 0.5~8.5kgf/cm2 | ||||
Ambient and media temperature | 5~60 celsius degree | ||||
Filtration | 40um | ||||
Body material | Aluminum Die-casting | ||||
Bowl material | Polycarbonate | ||||
Cup cover | - | steel | |||
Weight | 0.14kgs | 0.33kgs | |||
