Product Usage Range:
High pressure solenoid valves are widely used in military、aerospace、marine industry、petrochemical、power、chemical、light industry、machinery、scientific research、industrial furnaces、drying equipment、water supply and drainage、fire、food medical、cleaning equipment、 fountains、water plants Media automation control field.
Product Features:
1.Patented technology, unique design;
2.Spool for the pilot piston structure, stable performance;
3.Dynamic sealing performance is high, the switch is fast;
4.Autocratic coil, not easy to burn, a long time to stop the action to restart, the same action sensitive;
5.Coil power consumption is small, long life.
Specification:
Diameter range | DN0.5—DN300 |
Pressure range | 0.1-300MPA |
Applicable media | water、gas、oil、corrosive fluid etc |
Control method | normally open、normally closed、self-sustaining |
Body material | stainless steel |
Voltage | DC12-220V AC24-380V |
Medium temperature | (-200、-50) ~ (+120、+400)℃ |
Connection method | flange、welding、internal thread(external thread and special interface can be customized or adapter) |
Medium viscosity | less than 50 C St(more than required custom) |
Protective performance | dust-proof,waterproof,explosion-proof.According to working conditions |
Wiring method | terminal type; lead type; plug type |
