ZS 2/2way Direct Acting Solenoid Valve

INQUIRY

Feature

Direct acting working type, normally open and normally closed are available.

Brass material and stainless steel material are used on the body.

Different voltage are available.

The coils conforms Nass coil standard.

Specification

Normally Closed

Model	Thread size (G)	Orifice (mm)	CV value	Working pressure (Bar)
				AC			DC
				air, gas	water	oil	air, gas	water	oil
ZS030-06	1/8	3	0.3	0-10	0-10	0-7	0-7	0-7	0-5
ZS030-08	1/4	3	0.3	0-10	0-10	0-7	0-7	0-7	0-5
ZS040-08	1/4	4	0.58	0-5	0-5	0-4	0-4	0-4	0-3
ZS050-08	1/4	5	0.65	0-4	0-4	0-3	0-3	0-3	0-2
ZS060-08	1/4	6	0.8	0-10	0-10	0-10	0-7	0-7	0-7
ZS150-10	3/8	15	4.6	0-10	0-10	0-10	0-7	0-7	0-7
ZS150-15	1/2	15	4.6	0-10	0-10	0-10	0-7	0-7	0-7
ZS200-20	3/4	20	8.5	0-10	0-10	0-10	0-7	0-7	0-7
ZS250-25	1	25	12	0-10	0-10	0-10	0-7	0-7	0-7
ZS320-35	1 1/4	32	24	0-10	0-10	0-10	0-7	0-7	0-7
ZS400-40	1 1/2	40	29	0-10	0-10	0-10	0-7	0-7	0-7
ZS500-50	2	50	48	0-7	0-7	0-7	0-5	0-5	0-5
ZS250-25F	4 holes flange		12	0-10	0-10	0-10	0-7	0-7	0-7
ZS320-35F		32	24	0-10	0-10	0-10	0-7	0-7	0-7
ZS400-40F		40	29	0-10	0-10	0-10	0-7	0-7	0-7
ZS500-50F		50	48	0-7	0-7	0-7	0-5	0-5	0-5
ZS030-06B	1/8	3	0.3	0-10	0-10	0-7	0-7	0-7	0-5
ZS030-08B	1/4	3	0.3	0-10	0-10	0-7	0-7	0-7	0-5
ZS040-08B	1/4	4	0.58	0-5	0-5	0-4	0-4	0-4	0-3
ZS050-08B	1/4	5	0.65	0-4	0-4	0-3	0-3	0-3	0-2
ZS060-08B	1/4	6	0.8	0-10	0-10	0-10	0-7	0-7	0-7
ZS150-10B	3/8	15	4.6	0-10	0-10	0-10	0-7	0-7	0-7
ZS150-15B	1/2	15	4.6	0-10	0-10	0-10	0-7	0-7	0-7
ZS200-20B	3/4	20	8.5	0-10	0-10	0-10	0-7	0-7	0-7
ZS250-25B	1	25	12	0-10	0-10	0-10	0-7	0-7	0-7
ZS320-35B	1 1/4	32	24	0-10	0-10	0-10	0-7	0-7	0-7
ZS400-40B	1 1/2	40	29	0-10	0-10	0-10	0-7	0-7	0-7
ZS500-50B	2	50	48	0-7	0-7	0-7	0-5	0-5	0-5
ZS250-25FB	4 holes flange		12	0-10	0-10	0-10	0-7	0-7	0-7
ZS320-35FB		32	24	0-10	0-10	0-10	0-7	0-7	0-7
ZS400-40FB		40	29	0-10	0-10	0-10	0-7	0-7	0-7
ZS500-50FB		50	48	0-7	0-7	0-7	0-5	0-5	0-5

Normally Open

Model	Thread size (G)	Orifice (mm)	CV value	Working pressure (Bar)
				AC			DC
				air, gas	water	oil	air, gas	water	oil
ZS030-06H	1/8	3	0.3	0-7	0-7	0-6	0-6	0-6	0-4
ZS030-08H	1/4	3	0.3	0-7	0-7	0-6	0-6	0-6	0-4
ZS040-08H	1/4	4	0.58	0-4	0-4	0-3	0-3	0-3	0-2
ZS050-08H	1/4	5	0.65	0-3	0-3	0-2	0-2	0-2	0-1
ZS060-08H	1/4	6	0.8	0-5	0-5	0-3	0-3	0-3	0-3
ZS150-10H	3/8	15	4.6	0-5	0-5	0-3	0-3	0-3	0-3
ZS150-15H	1/2	15	4.6	0-5	0-5	0-3	0-3	0-3	0-3
ZS200-20H	3/4	20	8.5	0-5	0-5	0-3	0-3	0-3	0-3
ZS250-25H	1	25	12	0-5	0-5	0-3	0-3	0-3	0-3
ZS320-35H	1 1/4	32	24	0-5	0-5	0-3	0-3	0-3	0-3
ZS400-40H	1 1/2	40	29	0-5	0-5	0-3	0-3	0-3	0-3
ZS500-50H	2	50	48	0-5	0-5	0-3	0-3	0-3	0-3
ZS250-25FH	4 holes flange		12	0-5	0-5	0-3	0-3	0-3	0-3
ZS320-35FH		32	24	0-5	0-5	0-3	0-3	0-3	0-3
ZS400-40FH		40	29	0-5	0-5	0-3	0-3	0-3	0-3
ZS500-50FH		50	48	0-5	0-5	0-3	0-3	0-3	0-3
ZS030-06BH	1/8	3	0.3	0-5	0-5	0-3	0-3	0-3	0-3
ZS030-08BH	1/4	3	0.3	0-5	0-5	0-3	0-3	0-3	0-3
ZS040-08BH	1/4	4	0.58	0-5	0-5	0-3	0-3	0-3	0-3
ZS050-08BH	1/4	5	0.65	0-5	0-5	0-3	0-3	0-3	0-3
ZS060-08BH	1/4	6	0.8	0-5	0-5	0-3	0-3	0-3	0-3
ZS150-10BH	3/8	15	4.6	0-5	0-5	0-3	0-3	0-3	0-3
ZS150-15BH	1/2	15	4.6	0-5	0-5	0-3	0-3	0-3	0-3
ZS200-20BH	3/4	20	8.5	0-5	0-5	0-3	0-3	0-3	0-3
ZS250-25BH	1	25	12	0-5	0-5	0-3	0-3	0-3	0-3
ZS320-35BH	1 1/4	32	24	0-5	0-5	0-3	0-3	0-3	0-3
ZS400-40BH	1 1/2	40	29	0-5	0-5	0-3	0-3	0-3	0-3
ZS500-50BH	2	50	48	0-5	0-5	0-3	0-3	0-3	0-3
ZS250-25FBH	4 holes flange		12	0-5	0-5	0-3	0-3	0-3	0-3
ZS320-35FBH		32	24	0-5	0-5	0-3	0-3	0-3	0-3
ZS400-40FBH		40	29	0-5	0-5	0-3	0-3	0-3	0-3
ZS500-50FBH		50	48	0-5	0-5	0-3	0-3	0-3	0-3
